Oerlikon Leycon BAV_40_EP_AI_24VDC Angle Valve

Oerlikon Leybold Leycon BAV 40 EP AI 24VDC: High-Performance Angle Vacuum Valve

The Oerlikon Leybold Leycon BAV 40 EP AI 24VDC is a high-quality angle vacuum valve designed for reliable and efficient sealing in vacuum systems. This used unit has been thoroughly tested and is in excellent working condition, providing a cost-effective solution for your vacuum applications.

Specifications:

• Manufacturer: Oerlikon Leybold
• Model Number: BAV 40 EP AI 24VDC
• Nominal Diameter: DN 40
• Flange Type: ISO-KF
• Operating Voltage: 24 V DC
• Current Consumption: 5 - 100 mA
• Protection Class: IP 50
• Housing Material: Aluminum
• Weight: Approximately 1.068 kg
• Condition: Used, tested working

Features and Benefits:

✔ Compact Design: Space-saving and easy to integrate into existing systems.
✔ High Reliability: Robust construction ensures long service life and consistent performance.
✔ Fast Operation: Short opening and closing times improve process efficiency.
✔ Easy Integration: Standard DN 40 ISO-KF flange ensures seamless compatibility.
✔ Cost-Effective: Used unit provides significant savings without compromising performance.

Usage and Applications:

Ideal for use in coating technology, analytical applications, and research systems where reliable vacuum sealing is critical. Designed to meet industry standards for quality and performance.

Condition and Warranty:

This unit was part of a working PVD sputtering machine (manufactured by the German company FHR Anlagenbau GmbH) until it was disassembled. It is sold as-is, with no additional warranty.

Availability:

Serial numbers listed above are ready for immediate shipment.
